Navigator 485
Navigator 485
A more compact alternative to the 520, the Navigator 485 is similarly an ideal support boat for a sailing fleet, as well as a safe and affordable option for fun with family and friends. The Navigator 485 retains the generous 7′ 7″ beam of its larger siblings. Along with the square bow and extra-wide tubes this provides exceptional sea-keeping capabilities and superb stability—the dry and comfortable ride that you can expect from BRIG.
Length 15′ 11″ |
Width 7′ 7″ |
Empty Boat Weight 651 lbs |
Persons 8 |
Max HP 75 |
Fuel Tank 18 Gal |
Additional information
Specifications
- Length (ft) 15′ 11″
- Width (ft) 7′ 7″
- Height (ft) 6′ 3″
- Tube diameter (ft) 1′ 8″
- No. of Chambers 5
- Max No. of Persons 8
- Empty Boat Weight (lbs) 651
- Wet Weight (lbs) 1390
- Maximum payload (lbs) 2036
- Minimum power (hp) 40
- Recommended power (hp) 60
- Maximum power (hp) 75
- Design category C
- Engine shaft length 20”
- Fuel Tank Capacity 18 Gal
Features
- Deep V hull
- Anti-skid deck surface
- Front and rear stowage lockers
- Hull ventilation system
- Twin self-bailing unit
- Built-in fuel tank with external deck filler
- Front step-plate
- Front towing bow ring
- Rear cleats (bollards)
- Built-in davit lifting points
- Rubbing strake
- Safety handles & carrying handles
- 2 paddles & foot pump
- Repair kit
- Accessories bag
- Owner’s manual
- Steering console
- Steering system (mechanical)
- Steering wheel
- Automatic bilge pump
- Battery container
- Battery isolation switch
- Fuel gauge
- Rear towing points
- Front locker removable cushion
- Rear cushion with soft back
Options
- Steering system (Hydraulic)
- Marine compass
- Lifting slings
- Bow sundeck
- Console cover
- Stainless steel arch with navigation lights
- Ski towing point
- SeaDek
- Hypalon ORCA Fabric
